How to generate accurate segmentation masks using object detection and Meta SAM2

Segmentation masks are vital for precise object tracking and analysis, allowing pixel-level identification of objects. By leveraging a fine-tuned Ultralytics YOLO11 model alongside the Segment Anything 2 (SAM2) model, you can achieve unparalleled accuracy and flexibility in your workflows.

Hardware and software setup for this project

• CPU: Intel® Core™ i5-10400 CPU @ 2.90GHz for efficient processing.
• GPU: NVIDIA RTX 3050 for real-time tasks.
• RAM and Storage: 64 GB RAM and 1TB hard disk for seamless performance.
• Model: Fine-tuned YOLO11 model for object detection.
• Dataset: Custom annotated dataset for maximum accuracy.

How to generate segmentation masks

Step 1: Prepare the model

Train or fine-tune a custom YOLO11 model, or use the Ultralytics Pretrained Models for object detection tasks.

Step 2: Auto annotation with SAM2

Integrate the SAM2 model to convert bounding boxes into segmentation masks.

# Install the necessary library
# pip install ultralytics

from ultralytics.data.annotator import auto_annotate

# Automatically annotate images using YOLO and SAM2 models
auto_annotate(data="Path/to/images/directory",
              det_model="yolo11n.pt",
              sam_model="sam2_b.pt")

Step 3: Generate and save masks

Run the script to save segmentation masks as .txt files in the images_auto_annotate_labels folder.

Step 4: Visualize the results

Use the following script to overlay segmentation masks on images.

import os
import cv2
import numpy as np
from ultralytics.utils.plotting import colors

# Define folder paths
image_folder = "images_directory"   # Path to your images directory
mask_folder = "images_auto_annotate_labels" # Annotation masks directory
output_folder = "output_directory"  # Path to save output images

os.makedirs(output_folder, exist_ok=True)

# Process each image
for image_file in os.listdir(image_folder):
    image_path = os.path.join(image_folder, image_file)
    mask_file = os.path.join(mask_folder,
                             os.path.splitext(image_file)[0] + ".txt")

    img = cv2.imread(image_path)   # Load the image
    height, width, _ = img.shape

    with open(mask_file, "r") as f:  # Read the mask file
        lines = f.readlines()

    for line in lines:
        data = line.strip().split()
        color = colors(int(data[0]), True)

        # Convert points to absolute coordinates
        points = np.array([(float(data[i]) * width, float(data[i + 1])*height)
                           for i in range(1, len(data), 2)],
                           dtype=np.int32).reshape((-1, 1, 2))

        overlay = img.copy()
        cv2.fillPoly(overlay, [points], color=color)
        alpha = 0.6
        cv2.addWeighted(overlay, alpha, img, 1 - alpha, 0, img)
        cv2.polylines(img, [points], isClosed=True, color=color, thickness=3)

    # Save the output
    output_path = os.path.join(output_folder, image_file)
    cv2.imwrite(output_path, img)
    print(f"Processed {image_file} and saved to {output_path}")

print("Processing complete.")

That's it! After completing Step 4, you'll be able to segment objects and view the total count for each segmented object in every frame.

Real-world applications

• Medical Imaging: Segment organs and anomalies in scans for diagnostics.
• Retail Analytics: Detect and segment customer activities or products.
• Robotics: Enable robots to identify objects in dynamic environments.
• Satellite Imagery: Analyze vegetation and urban areas for planning.
